Paper Cup With Handle machine

CL-12CH Paper Cup With Handle machine adopts frequency conversion speed regulation, automatic oiling and paper feeding, fast production speed, up to 80-100 per minute.

Get a free quote DownLoad

CL-12CH Paper Cup Forming Machine With Cup Handle

Product Details

CL-12CH Paper Cup With Handle machine with cup handle is a multi-station paper cup forming machine. The machine adopts variable frequency speed regulation, automatic oiling, automatic paper feeding, ultrasonic welding, servo bottom paper feeding, high production speed, up to 80-100 per minute, and the cost performance is higher than similar products.

Technical Parameters

1. The aluminum plate indexing adopts a 10-station open cam, with a smaller indexing angle, more stable transmission at the same speed, and more convenient and simpler maintenance and lubrication than the closed divider. The transmission parts in the machine have a large space, easy to operate and maintain, and can replace the old medium-speed models on the market.

2. Simple and convenient adjustment

3. The whole machine transmission adopts a gear transmission system, the transmission structure and lubrication system are simpler, the speed ratio is stable, and the noise is low.

4. The CL-12CH medium-speed cup handle paper cup forming machine has cup passing detection, cup tube forming detection, and automatic shutdown alarm for faults.

5. The process flow of the equipment is as follows:

Suction paper → cup handle bonding → cup tube bonding → cup bottom → cup tube → preheating 1 → preheating 2 → folding bottom → knurling → curling → cup placing → collecting materials

Model	CL-12CH
Weight	2800KG
Packing specification	2600x1300x1800
Total power	3-phase 380V，8KW
Air supply	0.5-0.8MPa，0.6m³/min
Capacity	80-100Pcs/min
Paper specification	Single/Double PE paper
Paper gram	150-350g/㎡
Paper cup size	6-10oz
