Automatic High Speed Slitting Machine
HSR-370 Automatic High Speed Slitting Machine is specially used for narrow width label slitting. It is with full servo motor and with max. speed 350m/min
HSR-370 Automatic High Speed Slitting Machine is specially used for narrow width label slitting. It is with full servo motor and with max. speed 350m/min
.png)
HSR-370 High speed slitting machine is developed by Denchern machinery co.,Ltd.Which mainly for Narrow web label slitting,.It adopts full servo driven system, taper tension control system, international famous web guide system, turret type rewinding system. It's suitable for different size inner cores slitting and rewinding.Whether it is acceleration, deceleration or stable operation, the servo motor can provide smooth and powerful power support to ensure stability and accuracy during the slitting process.
|
Model |
HSR-370 |
|
Speed |
350m/min |
|
Max. Feed Web |
370mm |
|
Max. Unwind Dia. |
800mm |
|
Max. Up Unwind Dia. |
450mm |
|
Max. Down Rewind Dia. |
700mm |
|
Razor Knife |
optional |
|
Circular Knife |
6 sets |
|
Precision |
±0.1mm |
|
Voltage |
380V.50HZ |
|
Power |
9kw |
|
Dimension9 (L*W*H) |
2200mm*1350mm*1350mm |
|
Weight |
1300kg |
Full servo motor drive, max speed can reach 350m/min
Web guide with ultrasonic sensor, it is suitable for paper and film material
Slitting unit
With rotary knife normally, razor knife can be installed as optional, slitting unit with plastic cover which and meet CE safety requirement.
Up turret rewind and down single rewinder, can put fast change air shaft
